FLOORLIT – The floors

FLOORLIT FCP FCB Carlier Plastiques
Floor panel with non-slip coating high resistance

Plywood core in pine or birch coated with glass fibres reinforced polyester resin and with a non-slip structure on the inside face.





FLOORLIT FPE

High density PET core coated with glass fibres reinforced polyester resin and with a non-slip structure on the inside face.









FLOORLIT honeycomb core

Honeycomb core in polypropylene coated with glass fibres reinforced polyester resin and with a non-slip structure on the inside face.


PRODUCT DETAILS


Thicknesses and weights

THICKNESS in mm 15 18 21 28    32
Weight kg/m2 FCP (Pine core) 11.9 13.2 14.5 20.3
Weight kg/m2 FCB (Birch core) 18.2
Weight kg/m2 FPE (PET core hith density) 11.0
Weight kg/m2 FNA (Honeycomb core) 10.0

Advantages :

High resistance to abrasion, easy to clean.


Glass reinforcement :

FCP (Pine core) & FCB (Birch core) : 1100 g/m²
FPE ( High density PET core) & FNA (Honeycomb core in polypropylene) : 2500 g/m2


Dimensions :

Maximum width  : 2600 mm          Standard  length:  13 550 mm


Standard colour :

Grey


Applications :

Floors for all types of vehicles , building, gangways, balconies.


Strength test  :

We carried out specific tests on a test bed and we did neither notice any residual deflection nor any visible damage.

Our panels fulfill the specifications of the norm NFT 57-950-1 – Please see also our user’s guide. Tolerances : Length : +/-3 mm if L < 3m, +/-5 mm if L > 3m //Width: +/- 3 mm/Thickness. : +/-1 mm/Diagonal diff.: 6 mm.  Weight : +/-10%.

This document has no contract value. Characteristics are only given for information and may be changed according to variations of raw materials. Our sales and conditions terms are available upon request or on our website.
