EU35ES / EU35S / EE50ES / EE70ES / EE100ES / EE70S / EE100S

Panel with a PU or PET foam core and 5 mm PET reinforcements.

Polyurethane (35kg/m³) or

PET (50/70/100Kg/m³) foam core

with one or two 5 mm reinforcement layers of 200Kg/m³ PET compatible with screws, coated on both sides with fibre glass reinforced polyester resin.

PRODUCT DETAILS

Foam density :

Core : 35 kg/m3 in PU or 50, 70 and 100 kg/m3 in PET.

Reinforcements PET : 200 kg/m3

Other density : on request.

Dimensions :

Standard length : up to 13 550 mm

Maximum height : 3070 mm

Other thicknesses, widths or lengths : upon request.

Variants / glass reinforcement: 1400 g/m² for 1 layer of PET reinforcement, 1600 g/m² for 2 layers of PET reinforcement.

NB: options for laminates with varying degrees of reinforcement are available: please contact us.

Advantages:

✔ Lightweight

✔ High mechanical strength

✔ Thermal & acoustic insulation

✔ Stability & durability
✔ Recyclability

✔ The 5 mm high-density reinforcement(s) facilitate the fixing of various components to the panel.

✔ Rot-proof compared to the equivalent PU-plywood panel (ISP)

Options:

Protection film.

Colored panels.

Floor covering: different non-slip coatings : standard, corundum or rice grain.

Special panels tailored to your requirements. Examples: panels with various reinforcements for the subsequent fixing of various equipment, conduits for electrical cabling, side walls with specific inserts, rebates…

Send us your drawings and we’ll assess them!

Applications:  lightweight, insulated and refrigerated bodies, roofs, mobile shops, partitions and interior fittings, supports for lightweight walls, shelters…

Our panels fulfill the specifications of the norm NFT 57-950-1 – Please see also our user’s guide. Tolerances : Length : +/-3 mm if L < 3m, +/-5 mm if L > 3m //Width: +/- 3 mm/Thickness. : +/-1 mm/Diagonal diff.: 6 mm, Weight: +/-10%.

This document has no contract value. Characteristics are only given for information and may be changed according to variations of raw materials. Our sales and conditions terms are available upon request or on our website.
